Product Details
Place of Origin: Guangdong, China
Brand Name: Rion
Certification: CE
Model Number: HDA437T
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $128/Pieces
Packaging Details: box
Delivery Time: 5-7 days
Payment Terms: T/T, PayPal
Supply Ability: 5000/month
Power Supply: |
9~36v |
Dynamic Accuracy: |
0.1deg |
Resolution: |
0.01deg |
Static Accuracy: |
0.05deg |
Acceleration Range: |
±8g |
Gyro Range: |
±250°/s |
Weight: |
165g |
Name: |
Dynamic 3 Axis Tilt Transducer Anti Vibration Inclination Sensor |
Power Supply: |
9~36v |
Dynamic Accuracy: |
0.1deg |
Resolution: |
0.01deg |
Static Accuracy: |
0.05deg |
Acceleration Range: |
±8g |
Gyro Range: |
±250°/s |
Weight: |
165g |
Name: |
Dynamic 3 Axis Tilt Transducer Anti Vibration Inclination Sensor |
HDA437T MEMS Dynamic 3 Axis Tilt Transducer Anti-Vibration Inclination Sensor for Railway/Drilling/Ship Navigation
Datasheet download through click here ...
HDA436T HIGH-PRECISION DYNAMIC TILT SENSOR FOR CRA...
▶ KEY FEATURES
★ Range (Roll angle ±180°, pitch angle ±90°, azimuth angle ±180°)
★ Dynamic accuracy: ± 0.1°
★ Static accuracy: ± 0.05°
★ RS485/232/TTL output Optional
★ Wide temperature operation -40~+ 85℃
★ DC 9~6V wide voltage input
★ Resolution 0.01°
★ IP67/IP68 Protection level Optional
▶ PRODUCT APPLICATION
★ High vibration impact gravel equipment
★ Railway locomotive monitoring
★ Oil drilling equipment
★ Shield pipe jacking application
★ Shield pipe jacking application
★ Geological equipment tilt monitoring
★ Underground drilling rig attitude navigation
★ Ship navigation attitude measurement
★ Satellite communication vehicle attitude detection
★ Orientation measurement based on inclination angle
★ Various engineering machinery inclination measurement
▶ SPECIFICATIONS
| HDA436T |
CONDITION | INDEX | |
| Measure range | - |
Roll ±180°, pitch ±90°, azimuth ±180° (initial value at power-down is 0°) |
|
| Measure axis | - | X axis / Y axis / Z axis | |
| Resolution | - | 0.01° | |
| Static accuracy | @25℃ | ± 0.05° | |
| Dynamic accuracy(RMS) | @25℃ | ± 0.1° | |
| Gyro | range | - | ±250°/s |
| Zero bias stability (10s mean) | - | 8.5°/h | |
| Zero Bias Instability(allan) | - | 4.5°/h | |
| Angle random walk coefficient(allan) | - | 0.25°/sqrt(h) | |
| Acceleration | range | - | ±8g |
| Bias stability(10s mean) | - | 0.02mg | |
| Bias instability(allan) | - | 0.005mg | |
| Speed random walk coefficient(allan) | - | 0.005m/s/sqrt(h) | |
| Zero point temp. coefficient | -40～85℃ | ±0.01°/℃ | |
| Sensitivity temp. coefficient | -40～85℃ | ≤100ppm/℃ | |
| Power-on startup time | 1S | ||
| Response time | 0.01S | ||
| Output signal | RS485/RS232/TTL | ||
| Electromagnetic compatibility | According to EN61000 and GBT17626 | ||
| MTBF | ≥ 98000 hours / time | ||
| Insulation resistance | ≥100 Megohm | ||
| Impact resistance | 100g @ 11ms,3 axial direction (half sinusoid) | ||
| Anti-vibration | 10grms,10～1000Hz | ||
| Waterproof level |
standard configuration: IP67 optional configuration: IP68 or IP68 with anti-corrosion cable |
||
| Cable | Standard without wiring, optional 2m M12 aviation plug with PVC unshielded cable | ||
| Weight | ≤165g (excluding cables) | ||
INSTALLATION METHOD
▶ MECHANICAL PARAMETERS
○ Connector: M12 aviation plug 5P connector
○ Protection level: IP67
○ Shell material: frosted aluminum alloy
○ Installation: Four M4 screws
