MTBF Single Axis Inclinometer High Sensitivity Wearproof Cables

Product Details

Place of Origin: China

Brand Name: RION

Certification: CE, ISO

Model Number: MDA410

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $35.00/Pieces 1-99 Pieces

Packaging Details: CARTON

Delivery Time: 7 days for samples

Payment Terms: T/T, PayPal

Supply Ability: 50000/month

Get Best Price
Contact Now
Specifications
Highlight:

MTBF Single Axis Inclinometer

,

Single Axis Inclinometer high Sensitivity

,

wearproof Cables single axis tilt sensor

Usage:
Level Sensor
Theory:
MEMS
Output:
Analog SENSOR
Output Type:
0-5V
Model Number:
MDA420T
Measuring Axis:
X/Y
Power Supply:
DC 9~36V
Measuring Range:
Within ±360°
Output:
0~5v
Static Accuracy:
0.3
Dynamic Accuracy:
0.8
Anti-vibration:
100g@11ms
Protection Class:
IP67
Size:
L61x W35 X H21mm
Usage:
Level Sensor
Theory:
MEMS
Output:
Analog SENSOR
Output Type:
0-5V
Model Number:
MDA420T
Measuring Axis:
X/Y
Power Supply:
DC 9~36V
Measuring Range:
Within ±360°
Output:
0~5v
Static Accuracy:
0.3
Dynamic Accuracy:
0.8
Anti-vibration:
100g@11ms
Protection Class:
IP67
Size:
L61x W35 X H21mm
Description
MTBF Single Axis Inclinometer High Sensitivity Wearproof Cables
Product Description

MTBF Single Axis Inclinometer High Sensitivity wearproof Dynamic Inclinometer





Description
The MDA410T series is a new dynamic measuring small-volume MEMS tilt sensor from RION that accurately measures the attitude of the motion carrier. The built-in dual-channel Earth Gravity Inclination Unit converts into a tilt angle change by measuring static gravitational acceleration. Thereby the tilt and pitch angle of the sensor output relative to the horizontal plane can be measured. Output 0~5v. Due to the built-in MCU control system, the linearity of the sensor output is quadraticized, which compensates for the accuracy of the analog type due to insufficient correction.

This product adopts non-contact measurement original quantity, which can output the current attitude inclination angle in real time. It is easy to use and does not need to retrieve the two surfaces of relative change. This product is suitable for static and dynamic measurement. It is an ideal choice for industrial automation control and platform measurement attitude. It has strong resistance to external electromagnetic interference and can adapt to long-term work in industrial harsh environment.





Feature


●Dynamic biaxial tilt measurement
●range:±30°
●Static accuracy:±0.3°
●DC 9~36V power supply
●working temp. -40~+85℃
●resolution0.01°
●IP67
●anti-vibration >2000g
●direct lead wire

●size:L61×W35×H21mm

Application
● Satellite antenna search star

● Rail-mobile monitoring
●Tilt angle measurement of High-altitude construction machinery

●oil-well drilling equipment
●Radar detection of vehicle platform

●Underground drill posture navigation
●Gun Barrel angle measurement in early shooting

●Based on the angle direction measurement

●Satellite communications vehicle posture detection

●Shield pipe jacking application
●Ship's navigation posture measurement

●Geological equipment inclined monitoring



Technical Data:

Parameters
Conditions
MDA420T-30
Unit
Measuring range

±30
°
Measuring axis

X/Y

Resolution

0.1
°
Static accuracy
@25℃
± 0.3
°
Dynamic accuracy
@25℃
± 0.8
°
Zero temperature coefficient
-40~85°
±0.01
°/℃
Sensitivity temperature coefficient
-40~85°
≤100
ppm/℃
Power on time

1
S
Response time

0.05
s
Output signal
0~5v

EMC
According to EN61000 and GBT17626

MTBF
≥50000hours/times

Insulation Resistance
≥100M

Shockproof
100g@11ms,3Times/Axis(half sinusoid))

Anti-vibration
10grms,10~1000Hz

Protection glass
IP67

Cables
Standard 1M length,wearproof,grease proofing,wide temperature,Shielded cables 4*0.3mm2

Weight
120g(without cable)




*This Technical data only list ± 30 °, series for reference, other measuring range please refer to the adjacent parameters.
