Product Details
Place of Origin: Guangdong, China
Brand Name: RION
Certification: CE, ISO
Model Number: MDA426T-CAN2.0B
Payment & Shipping Terms
Minimum Order Quantity: 1 Pieces
Price: $30.00 - $35.00/Pieces
Packaging Details: CARTON
Delivery Time: 7 days for samples
Payment Terms: T/T, Paypal
Supply Ability: 50000 pcs per Month
Output: |
Digital Sensor |
Product Name: |
Dynamic-Static Dual Mode Inclinometer |
Measuring Axis: |
X/Y |
Power Supply: |
DC 9~36V |
Measuring Range: |
±1~±90° |
Output: |
CAN2.0B |
Static Accuracy: |
0.02 |
Dynamic Accuracy: |
0.3 |
Anti-vibration: |
>2000g |
Protection Class: |
IP67 |
Size: |
72.62*42*23.1mm |
Port: |
SHENZHEN |
Output: |
Digital Sensor |
Product Name: |
Dynamic-Static Dual Mode Inclinometer |
Measuring Axis: |
X/Y |
Power Supply: |
DC 9~36V |
Measuring Range: |
±1~±90° |
Output: |
CAN2.0B |
Static Accuracy: |
0.02 |
Dynamic Accuracy: |
0.3 |
Anti-vibration: |
>2000g |
Protection Class: |
IP67 |
Size: |
72.62*42*23.1mm |
Port: |
SHENZHEN |
Description
The MDA416T-MDA426T series is a new dynamic measuring small-volume MEMS tilt sensor from RION that accurately measures the attitude of the motion carrier. The built-in dual-channel Earth Gravity Inclination Unit converts into a tilt angle change by measuring static gravitational acceleration. Thereby the tilt and pitch angle of the sensor output relative to the horizontal plane can be measured. Output mode CAN2.0B level interface standard is optional. Due to the built-in MCU control system, the linearity of the sensor output is quadraticized, which compensates for the accuracy of the analog type due to insufficient correction.
This product adopts non-contact measurement original quantity, which can output the current attitude inclination angle in real time. It is easy to use and does not need to retrieve the two surfaces of relative change. This product is suitable for static and dynamic measurement. It is an ideal choice for industrial automation control and platform measurement attitude. It has strong resistance to external electromagnetic interference and can adapt to long-term work in industrial harsh environment.
Feature
●size:L61×W35×H21mm
Application
● Satellite antenna search star
● Rail-mobile monitoring
●Tilt angle measurement of High-altitude construction machinery
●oil-well drilling equipment
●Radar detection of vehicle platform
●Underground drill posture navigation
●Based on the angle direction measurement
●Satellite communications vehicle posture detection
●Shield pipe jacking application
●Ship's navigation posture measurement
●Geological equipment inclined monitoring
Technical Data:
Horizontal installation: be parallel between two surfaces:
Note: horizontal installation is factory default, if need vertical installation, please confirm
with sales.
