MCA410/420T LOW-COST FULL-ATTITUDE TILT SENSORS WITH HIGH RELIABILITY

Name: MCA410/420T LOW-COST FULL-ATTITUDE TILT SENSORS WITH HIGH RELIABILITY
Brand: Shenzhen Rion Technology Co., Ltd.
SKU: MCA410/420T
Price: 30 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: RION

Certification: CE

Model Number: MCA410/420T

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 30

Packaging Details: carton box with sponge

Delivery Time: 5 days for samples

Payment Terms: T/T,paypal

Supply Ability: 5000/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      Gyro Angular Rate Sensor, MEMS Angular Rate Sensor, 3 Axis MEMS Gyroscope Sensor


Output Voltage:	0~5V	0~5:	0. 1°
Accuracy:	± 0.2°	Response Time:	0.05S
Output Load:	>500 Ohm	Working Time:	50000 Hours/time( No Fault)

Output Voltage:	0~5V
0~5:	0. 1°
Accuracy:	± 0.2°
Response Time:	0.05S
Output Load:	>500 Ohm
Working Time:	50000 Hours/time( No Fault)

Description

MCA410/420T LOW-COST FULL-ATTITUDE TILT SENSORS WITH HIGH RELIABILITY

MCA410/420T LOW-COST FULL-ATTITUDE TILT SENSORS WITH HIGH RELIABILITY

▶ APPLICATION

●Agricultural machinery ●Lifting machinery ●Crane ●Aerial platform

●Solar tracking system ●Medical equipment ●Electric vehicle control

▶ INTRODUCTION

The MCA410/420T series represents a new generation of low-cost, full-attitude tilt sensors designed for industrial applications. Featuring an advanced anti-interference platform and incorporating high-precision capacitive MEMS sensing units, these sensors deliver excellent performance across wide temperature ranges and offer outstanding resistance to vibration. Engineered for long-term reliability, they provide a stable operating life of up to 10 years.

Utilizing a non-contact measurement principle, the MCA410/420T series calculates real-time tilt angles by detecting the Earth's gravitational components through its internal MEMS unit. Installation is quick and straightforward—requiring only attachment to the target object without the need for fixed or rotating shafts. With flexible mounting options, these sensors adapt easily to various usage scenarios.

Compact, durable, and easy to integrate, the MCA410/420T series is an ideal solution for construction machinery, agricultural equipment, and a wide range of industrial automation applications.

▶PARAMETERS

MCA410T/420T	CONDITIONS	PARAMETER	UNIT
Output Voltage		0~5	V
Resolution		0. 1		°
Accuracy	25℃	± 0.2		°
Response Time		0.05		S
Temperatu Re Drift	-40℃ ~ 85℃	± 0.5		°
Output Load	>500 ohm
Working Time	50000 hours/time( no fault)
Insulation Resistance	>100 ohm
Anti-shock	10grms,10~ 1000Hz
Impact Resistance	100g@11ms,3 Axial Direction (Half Sinusoid)
shell material	Electroplated metal housing
Weight	≤200g ( Including 1 m line)
Certiﬁcate	CE ; APPEARANCE PATENT
Quality System	IATF16949: 2016 (Certiﬁcate No.: T 178487) GJB9001C-2017 (Registration No.: 02622J3179R0M)

MCA410/420T LOW-COST FULL-ATTITUDE TILT SENSORS WITH HIGH RELIABILITY 0
