HCA510T-N IGH-PRECISION ANALOG VOLTAGE OUTPUT SINGLE / DUAL AXIS INCLINATION SENSOR.

Name: HCA510T-N IGH-PRECISION ANALOG VOLTAGE OUTPUT SINGLE / DUAL AXIS INCLINATION SENSOR.
Brand: Shenzhen Rion Technology Co., Ltd.
SKU: TL725D-RS232
Price: 179.00 USD
Availability: InStock

Product Details

Place of Origin: Guangdong, China

Brand Name: Rion

Certification: CE, ISO

Model Number: TL725D-RS232

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $358.00/Pieces >=1 Pieces

Packaging Details: 1pcs/box with sponge inside, 100pcs/ctn

Delivery Time: 7 days for samples

Payment Terms: T/T,Paypal

Supply Ability: 3000 Piece/Pieces per Month

Get Best Price

Contact Now

Specifications

Description

Ratings & Reviews

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              RS232 Gyro Sensor, AGM Mini Gyroscope Sensor, RS485 AGM Sensor


Response Frequency:	20Hz	EMC:	According To EN61000 And GBT17626
MTBF:	≥98000 Hours/times	Insulation Resistance:	≥100MΩ
Shockproof:	100g@11ms、3 Axial Direction (Half Sinusoid)	Anti-vibration:	10grms、10～1000Hz
Protection Glass:	IP67	Power Supply:	9~36v

Response Frequency:	20Hz
EMC:	According To EN61000 And GBT17626
MTBF:	≥98000 Hours/times
Insulation Resistance:	≥100MΩ
Shockproof:	100g@11ms、3 Axial Direction (Half Sinusoid)
Anti-vibration:	10grms、10～1000Hz
Protection Glass:	IP67
Power Supply:	9~36v

Description

HCA510T-N IGH-PRECISION ANALOG VOLTAGE OUTPUT SINGLE / DUAL AXIS INCLINATION SENSOR.

HCA510T-N IGH-PRECISION ANALOG VOLTAGE OUTPUT SINGLE / DUAL AXIS INCLINATION SENSOR.

▶ FEATURE

★ Single / dual axis inclination measurement

★ Range ± 1～± 90° optional

★ Accuracy: Refer to technical data

★ Wide voltage input 11.5～36V

★ Wide temperature operation -40 ℃～+ 85 ℃

★ Output mode 0～5V

★ High vibration resistance> 2000g

★ IP67 protection

★ Small size L90 × W59 × H34mm

★ High resolution 0.0

▶APPLICATION

★ Equipment vehicle leveling

★ Bridge and Dam monitoring

★ High-altitude platform safety protection

★ Angle control of medical equipment

★ Attitude navigation of underground drilling rig

★ Leveling of railway gauge and gauge

★ Direction measurement based on tilt angle

★ Tilt monitoring of geological equipment

★ Mining machinery, oil drilling equipment

★ Equipment level control

★ Alignment control , curve control

▶ SPECIFICATIONS

HCA510T/HCA520T-N		CONDITION	PARAMTERS				UNIT
Measure range			±10	±30	±60	±90	°
Measure axis			X / XY	X / XY	X / XY	X / XY
Zero output		0° output	2.5	2.5	2.5	2.5	V
Resolution			0.001	0.001	0.001	0.001	°
Measure accuracy	MAXE	Room temp.	0.005	0.01	0.02	0.03	°
	RMSE	Room temp.	0.003	0.003	0.005	0.008	°
Zero Temp. coefficient		-40～85℃	0.0005	0.0005	0.0005	0.0005	°/℃
Sensitivity temp. coefficient		-40～85℃	≤100	≤100	≤100	≤100	ppm/℃
Power on time			0.5	0.5	0.5	0.5	S
Response frequency		20Hz
EMC		According to EN61000 and GBT17626
MTBF		≥98000 hours/times
Insulation Resistance		≥100MΩ
Shockproof		100g@11ms,3 Axial Direction (Half Sinusoid)
Anti-vibration		10grms,10～1000Hz
Protection glass		IP67
Cables		Standard 7 P * 6.8 mm aviation connector, 1 meter long, wear-resistant, wide temperature, shielded cable, cable weight ≤ 110 G
Weight		≤250g(Excluding cable)
