HCA516/526 Single Axis MEMS Inclinometer RION Mechanical Tilt Sensor

Product Details

Place of Origin: China

Brand Name: RION

Certification: CE, ISO

Model Number: HCA516/HCA526

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 328 USD/pcs

Packaging Details: carton

Delivery Time: 7 word days

Payment Terms: T/T, PayPal

Supply Ability: 1000 pcs/month

Get Best Price
Contact Now
Specifications
Highlight:

Single Axis MEMS Inclinometer

,

RION Mechanical Tilt Sensor

,

RS422 Single Axis MEMS Inclinometer

Measure Range:
±10°、±35°
Measure Axis:
X / XY
Resolution:
0.001°
Measure Accuracy:
0.005°
Long Term Stability:
0.01°
Zero Temp.coefficient:
±0.002°/℃
Weight:
≤250g(without Cable)
Protection Grade:
IP67
Measure Range:
±10°、±35°
Measure Axis:
X / XY
Resolution:
0.001°
Measure Accuracy:
0.005°
Long Term Stability:
0.01°
Zero Temp.coefficient:
±0.002°/℃
Weight:
≤250g(without Cable)
Protection Grade:
IP67
Description
HCA516/526 Single Axis MEMS Inclinometer RION Mechanical Tilt Sensor

HCA516/526 Single Axis MEMS Inclinometer RION Mechanical Tilt Sensor



TECHNICAL DATA

HCA516/526T-C1 CONDITION PARAMETERS UNIT
Measure range   ±10 ±35 °
Measure axis   X/XY X/XY axis
Resolution   0.001 0.001 °
Measure accuracy @25℃ 0.005 0.01 °(RMS)
Long term stability   0.01 0.02 °
Zero Temp.coefficient -40~85℃ ±0.002 ±0.002 °/℃

Sensitivity

temp. coefficient

-40~85℃ ≤50 ≤50 ppm/℃
Power on time   0.5 0.5 S
Response frequency   20 20 HZ
Output rate 5Hz,15Hz,35Hz,50Hz can be set
Output signal CANOPEN
EMC According to EN61000 and GBT17626
MTBF ≥98000hours/times
Insulation Resistance ≥100MΩ
Shockproof 100g@11ms,3 Axial Direction (Half Sinusoid)
Anti-vibration 10grms,10~1000Hz
Protection grade IP67
Cables Standard configuration: 1m length, wear-resistant, wide temperature, shielded cable 4*0.4mm2 aviation connector
Weight ≤250g(without cable)

*This parameter only list ± 10 °, ± 30 °, ± 60 °, and ± 90 ° series for reference. For other measurement ranges, please refer to the nearest neighbor parameter.



FEATURES

★ Single/Dual-Axis Inclinometer

★ Measuring Range :±1~±90° optional

★ Wide voltage input: 9~36V

★ Wide temperature working: -40~+85℃

★ Resolution: 0.001°

★ Water-proof air-plug connector

★ IP67 protection class

★ Highly anti-vibration performance >2000g

★ Small size :90×50×34mm(customized)



APPLICATION

★ Railway locomotive monitoring

★ Geological equipment tilt monitoring

★ Underground drilling rig attitude navigation

★ Direction measurement based on inclination

★ Oil drilling equipment

★ Ship navigation posture measurement

★ Radar vehicle platform detection

★ Shield pipe jacking application

★ Various construction machinery inclination measurement



HCA516/526 Single Axis MEMS Inclinometer RION Mechanical Tilt Sensor 0



HCA516/526 Single Axis MEMS Inclinometer RION Mechanical Tilt Sensor 1



HCA516/526 Single Axis MEMS Inclinometer RION Mechanical Tilt Sensor 2
