Product Details
Place of Origin: Guangdong, China
Brand Name: RION
Certification: CE
Model Number: HCA716S-60
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $250.00/Pieces 1-9 Pieces
Packaging Details: 1pcs/box ,100pcs/ctn
Delivery Time: 10 days for sample order
Payment Terms: T/T, PayPal
Supply Ability: 5000/month
Type: |
Angle Sensor |
Theory: |
Other |
Output: |
Modbus |
Axis: |
Single/dual |
Resolution: |
0.01degree |
Working Temp.: |
-40 To +85℃ |
Waterproof: |
IP67 |
Size: |
54x44x18mm |
OEM: |
YES |
Absolute Accuracy: |
±0.01deg |
Response Time: |
0.02s |
Interface: |
RS232 Or RS485 (MODBUS RTU) |
Type: |
Angle Sensor |
Theory: |
Other |
Output: |
Modbus |
Axis: |
Single/dual |
Resolution: |
0.01degree |
Working Temp.: |
-40 To +85℃ |
Waterproof: |
IP67 |
Size: |
54x44x18mm |
OEM: |
YES |
Absolute Accuracy: |
±0.01deg |
Response Time: |
0.02s |
Interface: |
RS232 Or RS485 (MODBUS RTU) |
|
HCA716&HCA726
|
PARAMETERS
|
|
|
|
UNIT
|
||||
|
Measuring range
|
±15
|
±45
|
±60
|
±180
|
°
|
||||
|
Measuring axis
|
X,Y
|
X,Y
|
X,Y
|
Vertical X axis
|
|
||||
|
Resolution
|
0.001
|
0.001
|
0.003
|
0.005
|
°
|
||||
|
Absolute accuracy
|
±0.008
|
±0.01
|
±0.01
|
±0.01
|
° RMS
|
||||
|
Long term stability
|
<0.02
|
<0.02
|
<0.02
|
<0.02
|
°
|
||||
|
Zero Temp.coefficient
|
±0.0005
|
±0.0005
|
±0.0005
|
±0.0005
|
°/℃
|
||||
|
Sensitivity temp-coefficient
|
≤0.01
|
≤0.01
|
≤0.01
|
≤0.01
|
S
|
||||
|
Power on time
|
0.5
|
0.5
|
0.5
|
0.5
|
S
|
||||
|
Response frequency
|
>20HZ
|
|
|
|
|
||||
|
Interface
|
RS232 or RS485 (MODBUS RTU)
|
|
|
|
|
||||
|
Insulation Resistance
|
≥100MΩ
|
|
|
|
|
||||
|
Anti-vibration
|
10grms,10～1000Hz
|
|
|
|
|
||||
|
Protection grade
|
IP67
|
|
|
|
|
||||
|
Cables
|
Standard configuration: 1m length, wear-resistant,oil-proof, wide temperature, shielded cable4*0.2mm2
|
|
|
|
|
||||
|
Weight
|
90g(without cable)
|
|
|
|
|
||||
