MCA416T/426T DIGITAL OUTPUT TILT SENSOR

Name: MCA416T/426T DIGITAL OUTPUT TILT SENSOR
Brand: Shenzhen Rion Technology Co., Ltd.
SKU: MCA416
Price: 35 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: RION

Certification: CE, ISO

Model Number: MCA416

Document: MCA416T MCA426T DIGITAL OUT...OR.pdf

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 35 USD

Packaging Details: Carton

Delivery Time: 2 work days

Payment Terms: T/T,Paypal

Supply Ability: 10000/month

Get Best Price

Contact Now

Specifications

Description

Ratings & Reviews

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              Tilt Sensor Inclinometer 1 Axis, PV Tilt Sensor Inclinometer, 0.3deg Single Axis Inclinometer


Resolution:	0.1°	Accuracy:	±0.2°
Output Load:	>500ohm	Weight:	60g
Output:	RS485/RS232/TTL	Power Supply:	9~36V
Work Temperature:	-40~+85°℃	Certificate:	CE;APPEARANCE PATENT

Resolution:	0.1°
Accuracy:	±0.2°
Output Load:	>500ohm
Weight:	60g
Output:	RS485/RS232/TTL
Power Supply:	9~36V
Work Temperature:	-40~+85°℃
Certificate:	CE;APPEARANCE PATENT

Description

MCA416T/426T DIGITAL OUTPUT TILT SENSOR

Product Description

This industrial-grade inclinometer sensor uses a third-order filter algorithm to measure pitch and roll angles relative to horizontal level. It maintains high repeatability across temperature extremes (-40°C to +85°C) with a response frequency up to 20Hz (customizable for higher frequencies). Designed for harsh industrial environments, it offers reliable performance, excellent expandability, and multiple output options.

Key Features

Accuracy: ±0.3°
Power Input: DC 9~36V
Operating Temperature: -40°C to +85°C
Resolution: 0.1°
IP67 Waterproof Rating
Anti-shock capability >2000g
Direct lead interface
Compact dimensions: 61×35×21mm
Output type: MODBUS

Technical Specifications

Parameter	Condition	Value	Unit
Resolution		0.1	°
Accuracy	@25℃	±0.2	°
Response Time		0.05	S
Zero temp. coefficient	-40～85°℃	±0.5	°
Output Interface	RS485/RS232/TTL
Output Load	>500ohm
Working Time	98000 hours/time (no fault)
Insulation resistance	≥100 megohm
Anti-vibration	10grms, 10～1000Hz
Impact Resistance	100g@11ms, 3 Axial Direction (Half Sinusoid)
Weight	<200g (Including 1 meter standard cable)
Waterproof grade	IP67
Certificate	CE; APPEARANCE PATENT
Quality System	IATF16949:2016 GJB9001C-2017 standard
