DMI610 Auto temperature drift compensation Single/dual Digital Inclinometer

Product Details

Place of Origin: Guangdong, China

Brand Name: RION

Certification: CE, RHOS

Model Number: DMI610

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiation

Packaging Details: 1pcs digital inclinometer in each plastic box with safe sponge inside

Delivery Time: 7 days for samples

Payment Terms: T/T, Paypal

Supply Ability: 3000/month

Get Best Price
Contact Now
Specifications
Highlight:

DMI610 Digital Inclinometer

,

Single/dual Digital Inclinometer

Product Name:
Digital Inclinometer
Best Accuracy:
0.005° @ Range ±30°
Angle Resolution:
0.001°
Maximum Measuring Range:
±90° ( Single Axis Only )
Working Temperature:
-10°~ +70℃
Three Mode:
Radian, Angle, Mm/m
Product Name:
Digital Inclinometer
Best Accuracy:
0.005° @ Range ±30°
Angle Resolution:
0.001°
Maximum Measuring Range:
±90° ( Single Axis Only )
Working Temperature:
-10°~ +70℃
Three Mode:
Radian, Angle, Mm/m
Description
DMI610 Auto temperature drift compensation Single/dual Digital Inclinometer

DMI610 Auto temperature drift compensation Single/dual Digital Inclinometer



Download datasheet please click below

DMI610 DIGITAL DISPLAY INCLINOMETER.pdf



 KEY FEATURES



★ Best accuracy:<0.02°

★ Repeatability:0.004°

★ Maximum measure range:±90°

★ Data store function

★ Absolute/Relative measurement can switch

★ Both sides and bottom can measure

★ Three surface datum strong magnetic installation

★ Working Temperature : -10°~ +70℃

★ Auto-angle interleaved compensation function

★ Auto temperature drift compensation

★ User can calibrate ZERO by himself

★ Night vision fours colors screen

★ Three kinds of measurement mode selectable (radian, angle, mm/m)

★ Angle resolution:0.001°





 Usage For

★ Building construction

★ Automobile four-wheel testing

★ Road slope

★ Machinery installation

★ Piping installation

★ Industrial platform

★ Turntable testing

★ Pan unit angle detection

★ Production jig

★ Medical instruments







DESCRIPTION



DMI610 has the function of data storage, 3 measurement modes (Degrees, minutes, seconds,angle,mm/m) optional, strong expansibility, convenient application, industrial reliability, and has the absolute competitive price advantage in the international market have absolute competitive advantage!



SPECIFICATIONS



DMI610 Auto temperature drift compensation Single/dual Digital Inclinometer 2DMI610 PARAMETERS
Angle measure range ±90° ±30°
Measure axis Single axis Dual axis
Best accuracy(RMS) <0.02°(Full range) <0.005°(Full range)
Angle measure resolution 0.001° 0.001°
Repeatability 0.004° 0.004°
Measurement mode radian, angle, mm/m three modes can be set
LCD 64 true colors night vision display screen
LCD visible area size L60.5*W45mm
Working temperature -10℃~+70℃
Working humidity 85%RH
Power supply One 2A AA battery or AA NiMH rechargeable battery
Ideal working time 6Hours
Shock resistance 10g@11ms,3 Axial Direction (Half Sinusoid)
Shock impact 10grms,10~100Hz
Weight 600g
Waterproof grade IP65
Material Anodic oxidation of aluminum alloy
Size L115*W95*H32mm
Precautions In order to achieve the highest measurement accuracy, please set the latitude information of the local city, and it will be automatically saved after setting. (Refer to the third point of the third point in the main interface function introduction of this specification)









DMI610 Auto temperature drift compensation Single/dual Digital Inclinometer 3



DMI610 Auto temperature drift compensation Single/dual Digital Inclinometer 4
