Product Details
Place of Origin: Guangdong, China
Brand Name: RION
Certification: CE, ISO
Model Number: HCM375-TTL
Payment & Shipping Terms
Minimum Order Quantity: 1 Units
Price: $450.00/Units
Packaging Details: 1pcs digital compass in each inner box , 200pcs /ctn
Delivery Time: 7 days for sample
Payment Terms: T/T, Paypal
Supply Ability: 1000 pcs per month
Heading Accuracy: |
0.5° |
Roll Measure Range: |
±180° |
Tilt Resolution: |
0.1° |
Tilt Accuracy: |
<0.2°(Full Range) |
Working Tempaccuracy: |
-40℃~+85℃ |
Dimension: |
L110×W19.5×H19.5mm |
Pitch Range: |
+/-85° |
Production: |
IP67 |
Heading Accuracy: |
0.5° |
Roll Measure Range: |
±180° |
Tilt Resolution: |
0.1° |
Tilt Accuracy: |
<0.2°(Full Range) |
Working Tempaccuracy: |
-40℃~+85℃ |
Dimension: |
L110×W19.5×H19.5mm |
Pitch Range: |
+/-85° |
Production: |
IP67 |
| HCM370B / HCM375B Index | ||
| Heading | Heading Accuracy | 0.5° Tilt < 10° |
| 2.0° Tilt < 60° | ||
| 3.0° Tilt < 80° | ||
| Resolution | 0.1° | |
| Tilt | Pitch Accuracy | 0.1°<15° (Measure Range) |
| 0.1°<30°(Measure Range) | ||
| 0.1°<60°(Measure Range) | ||
| 0.2°<85°(Measure Range) | ||
| Pitch Range | ±85° | |
| Roll Accuracy | 0.1°<15°(Measure Range) | |
| 0.1°<30°(Measure Range) | ||
| 0.1°<60°(Measure Range) | ||
| 0.2°<180°(Measure Range) | ||
| Roll Range | ±180° | |
| Resolution | 0.1° | |
| Calibration | Hard Magnetic Calibration | Available |
| Soft Magnetic Calibration | Available | |
| Magnetic Filed Interference Calibration Method |
Rotate 360° Horizontally; Vertical Rotation(Optional) |
|
| RS-232/RS485/TTL | 5Pin Quick Plug Connector | |
| Interface | Start Delay | <50ms |
| Max Output Rate | 20Hz/s | |
| Communication Rate | 2400 TO 19200baud | |
| Output Format | Binary High Performance Protocol | |
| Power Supply | Power Voltage | (Default)DC+5V |
| Current(Max) | 30ma | |
| Ideal Current | 26ma | |
| Sleep Mode | TBD | |
| Environment | Working Temp. | -40℃~+85℃ |
| Storage Temp. | -40℃~+100℃ | |
| Anti-Shock Performance | 100g | |
| Protection Level | IP67 | |
| Electromagnetic Compatibility | According TO EN61000 and BT17626 | |
| Mtbf | ≥40000 Hour/Time | |
| Insulation Resistance | ≥100M.O. | |
| Anit-Impact | 100g@11ms,3Times/Axis(Half Sinusoid) | |
| Anti--Shock | 10grms,10～1000Hz | |
| Dimension | L110×W19.5×H19.5mm | |
| Weight | 70g(Not Include Cable) | |
●With Hard And Soft Magnetic Calibration ●Rs232/Rs485/Ttl Output
