HCM505B Tilt Compensated 3D Digital Compass 40C Magnetic Sensor Roll Angle

Name: HCM505B Tilt Compensated 3D Digital Compass 40C Magnetic Sensor Roll Angle
Brand: Shenzhen Rion Technology Co., Ltd.
SKU: HCM505B
Price: 438 USD
Availability: InStock

Product Details

Place of Origin: Guangdong, China

Brand Name: RION

Certification: CE ISO

Model Number: HCM505B

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 438 USD/Pieces

Packaging Details: 1pcs in a box with sponge inside , 50pcs/ctn

Delivery Time: 7 days for samples

Payment Terms: T/T, Paypal

Supply Ability: 5000/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      HCM505B 3D Digital Compass, 3D Digital Compass Roll angle, 40C magnetic compass sensor


Usage:	Magnetic Sensor	Theory:	Capacitance Sensor
Heading Accuracy:	0.3-0.5	Roll Angle Range:	+/-180deg
Small Size:	L113 X W20 X H20mm	Output Interface:	RS232/RS485/TT: (optional)

Usage:	Magnetic Sensor
Theory:	Capacitance Sensor
Heading Accuracy:	0.3-0.5
Roll Angle Range:	+/-180deg
Small Size:	L113 X W20 X H20mm
Output Interface:	RS232/RS485/TT: (optional)

Description

HCM505B Tilt Compensated 3D Digital Compass 40C Magnetic Sensor Roll Angle

HCM505B Tilt Compensated 3D Digital Compass 40C Magnetic Sensor Roll Angle

Features:

Heading accuracy: 0.3°~0.5°
Roll angle measuring range :±180°
Tilt angle resolution: 0.1°
Tilt angle accuracy: 0.2°
Size: L113×W20×H20mm
Standard RS232/RS485/TTL output interface
Wide temperature : -40°C~+85°C

Applications:

Satellite antenna search satellite
Marine navigation surveying and mapping
GPS integrated navigation
Antenna servo control
Infrared imager
Laser range finder
Map for plotter
ROV underwater robot navigation
Oceanography measurement instruments

Technical data

HCM500B/505B
Compass heading parameter	The best heading accuracy	0.3° tilt <10°
	The best heading accuracy	1.0° tilt <180°
	Resolution	0.1°
Compass tilt parameter	Pitch accuracy	0.1°<15°(Measure range)
		0.1°<30°(Measure range)
		0.1°<60°(Measure range)
		0.2°<85°(Measure range)
	Pitch tilt range	±85°
	Roll accuracy	0.1°<15°(Measure range)
		0.1°<30°(Measure range)
		0.1°<60°(Measure range)
		0.2°<180°(Measuring range)
	Roll tilt range	±180°
	Resolution	0.1°
Calibration	Hard iron calibration	Yes
	Soft iron calibration	Yes
	Magnetic field interference calibration method	24 points(3D calibration)
Physical features	Dimension	L113×W20×H20mm
	Weight	80g(without cable)
	RS232/RS485/TTL interface connector	5PIN connector
Interface features	Start delay	<50MS
	Maximum output rate	20Hz/s
	Communication rate	2400 to19200baud
	Output format	Binary high performance protocol
Power	Power supply	(Default)DC+5V
	Power supply	(Customized)DC9～36V
	Current(Maximum)	20mA
	Ideal mode	18mA
	Sleep Mode	TBD
Enviroment	Operating range	-40℃～+85℃
	Storage temperature	-40℃～+85℃
	Resistance shock performance	2500g
Electromagnetic compatibility	According to EN61000 and GBT17626
MTBF	≥40000 hours/times
Insulation resistance	≥100M
Shock resistance	100g@11ms,3 Axial Direction (Half Sinusoid)
Anti-vibration	10grms,10～1000Hz
