DMI610 Digital Inclinometer Single / Dual Axis 2 Mode Horizontal Vertical Installation Tilt Sensor

Product Details

Place of Origin: Guangdong, China

Brand Name: RION

Certification: CE, RHOS

Model Number: DMI610

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $547.00/Pieces 1-499 Pieces

Packaging Details: 1pcs digital inclinometer in each plastic box with safe sponge inside

Delivery Time: 7 days for samples

Payment Terms: T/T, Paypal

Supply Ability: 3000/month

Get Best Price
Contact Now
Specifications
Highlight:

single axis digital inclinometer

,

2 mode digital inclinometer

,

dual axis high accuracy digital inclinometer

Digital Inclinometer Best Accuracy:
<0.02°
Repeatability:
0.02°
Angle Resolution:
0.001°
Maximum Measuring Range:
±90°
Data Store Function:
Yes
Working Temperature:
-10°~ +70℃
Night Vision Fours Colors Screen:
Yes
Three Mode:
Radian, Angle, Mm/m
User Can Calibrate ZERO By Himself:
Yes
Auto Temperature Drift Compensation:
Yes
Digital Inclinometer Best Accuracy:
<0.02°
Repeatability:
0.02°
Angle Resolution:
0.001°
Maximum Measuring Range:
±90°
Data Store Function:
Yes
Working Temperature:
-10°~ +70℃
Night Vision Fours Colors Screen:
Yes
Three Mode:
Radian, Angle, Mm/m
User Can Calibrate ZERO By Himself:
Yes
Auto Temperature Drift Compensation:
Yes
Description
DMI610 Digital Inclinometer Single / Dual Axis 2 Mode Horizontal Vertical Installation Tilt Sensor

DMI610 High Accuracy Single /dual axis Digital Inclinometer 2 Mode Horizontal Vertical Installation Tilt Sensor





Download the datasheet please click here below :

DMI610 DIGITAL DISPLAY INCLINOMETER.pdf



FEATURES



★ Best accuracy:<0.02°

★ Repeatability:0.004°

★ Maximum measure range:±90°

★ Data store function

★ Absolute/Relative measurement can switch

★ Both sides and bottom can measure

★ Three surface datum strong magnetic installation

★ Working Temperature : -10°~ +70℃

★ Auto-angle interleaved compensation function

★ Auto temperature drift compensation

★ User can calibrate ZERO by himself

★ Night vision fours colors screen

★ Three kinds of measurement mode selectable (radian, angle, mm/m)

★ Angle resolution:0.001°





APPLICATION



★ Building construction

★ Automobile four-wheel testing

★ Road slope

★ Machinery installation

★ Piping installation

★ Industrial platform

★ Turntable testing

★ Pan unit angle detection

★ Production jig

★ Medical instruments







GENERAL DESCRIPTION



DMI610 is a digital display inclinometer for various industry angle controling and measuring.

The core of this product use micro mechanical control principle, using RION patent interleaved temperature compensation model algorithm, play micro electronic mechanical principle of absolute operation advantage, to ensure the long-term stability and repeatability of measuring instrument. DMI610 single axis maximum range of up to + 90 ° , resolution 0.002 ° , the best accuracy <0.02° (in full measuring range), fast response speed, stable data , specially designed side and bottom the strong magnetic adsorption type installation, three datum can be measured using normally, bring great convenience to customers, DMI610 has the function of data storage, 3 measurement modes (Degrees, minutes, seconds,angle,mm/m) optional, strong expansibility, convenient application, industrial reliability, and has the absolute competitive price advantage in the international market have absolute competitive advantage!





DMI610 Digital Inclinometer Single / Dual Axis 2 Mode Horizontal Vertical Installation Tilt Sensor 2









DMI610 Digital Inclinometer Single / Dual Axis 2 Mode Horizontal Vertical Installation Tilt Sensor 3



DMI610 Digital Inclinometer Single / Dual Axis 2 Mode Horizontal Vertical Installation Tilt Sensor 4
