Product Details
Place of Origin: Guangdong, China
Brand Name: Rion
Certification: CE, ISO
Model Number: ACA6-N
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $680.00/Pieces >=1 Pieces
Packaging Details: 1pcs/box with sponge inside, 100pcs/ctn
Delivery Time: 7 days for samples
Payment Terms: T/T,Paypal
Supply Ability: 3000 Piece/Pieces per Month
Measure Range: |
±10~90° |
Measure Axis: |
X / XY |
Zero Output: |
12 MA |
Resolution: |
0.0007° |
Sensitivity Temp-coefficient: |
≤50 Ppm/℃ |
Response Frequency: |
20Hz |
Measure Range: |
±10~90° |
Measure Axis: |
X / XY |
Zero Output: |
12 MA |
Resolution: |
0.0007° |
Sensitivity Temp-coefficient: |
≤50 Ppm/℃ |
Response Frequency: |
20Hz |
ACA6-N ULTRA-HIGH PRECISION CURRENT OUTPUT TILT SENSOR INDUSTRIAL TILT MONITORING
ACA618T/ACA628T-N is a high-precision single/dual-axis tilt sensor with full temperature compensation and current output (4~20mA), designed for demanding industrial applications that require long-distance transmission and high stability.
Key Features:
Equipped with a 24-bit high-precision differential A/D converter, ensuring excellent output linearity with no need for user-side linear correction;
Integrated high-resolution temperature sensor, combined with an MCU for secondary temperature compensation, achieving zero drift as low as 0.0005°/°C; for small measurement ranges, accuracy can reach 0.003° at room temperature;
4–20mA current output offers superior resistance to interference and supports long-distance transmission up to 2 km, outperforming traditional voltage output;
Non-contact installation—simply mount the sensor on the object with screws, and it will automatically calculate the tilt angle without alignment;
Robust against electromagnetic interference and vibration, making it ideal for harsh environments;
Offers outstanding performance and compatibility, standing out among competing domestic products and well-suited for high-end industrial tilt monitoring.
▶ FEATURES
★ Single/Dual-Axis tilt sensor
★ Measure Range :±1~±90° optional
★ Wide voltage input: 11.5~36V
★ Wide temperature working: -40~+85℃
★ IP67 protection grade
★ Highly anti-vibration performance >2000g
★ High Resolution: 0.0007°
★ Temperature drift: 0.0005°/℃
★ Small range accuracy up to 0.003 °
▶ APPLICATION
★ Engineering vehicles automatic leveling
★ Bridge & dam detection
★ Laser equipment position
★ Medical facilities angle control
★ Underground drill posture navigation
★ Precise machine tool level control
★ Geological equipment inclined monitoring
★ Railway gauging rule , gauge equipment leveling
|
Conditions |
Parameters |
Unit |
||||
Measure range |
|
±10 |
±30 |
±60 |
±90 |
° |
|
Measure axis |
|
X / XY |
X / XY |
X / XY |
X / XY |
axis |
|
Zero output |
0° output |
12 |
12 |
12 |
12 |
mA |
|
Resolution |
|
0.0007 |
0.0007 |
0.0007 |
0.0007 |
° |
|
Measure accuracy |
MAXE |
Room temp. |
0.003 |
0.01 |
0.02 |
0.03 |
° |
RMSE |
Room temp. |
0.003 |
0.003 |
0.005 |
0.008 |
° |
|
Zero Temp. coefficient |
-40~85℃ |
0.0005 |
0.0005 |
0.0005 |
0.0005 |
°/℃ |
|
Sensitivity temp-coefficient |
-40~85℃ |
≤50 |
≤50 |
≤50 |
≤50 |
ppm/℃ |
|
Power on time |
|
0.5 |
0.5 |
0.5 |
0.5 |
S |
|
Response frequency |
20Hz |
||||||
EMC |
According to EN61000 and GBT17626 |
||||||
MTBF |
≥98000 hours/times |
||||||
Insulation Resistance |
≥100MΩ |
||||||
Shockproof |
100g@11ms,3 axial direction (half sinusoid) |
||||||
Anti-vibration |
10grms,10~1000Hz |
||||||
Protection grade |
IP67 |
||||||
Cables |
Standard 7 P * 6.8 mm aviation connector, 2m long, wear-resistant, wide temperature, shielded cable, cable weight ≤ 200 G |
||||||
Weight |
≤260g(without cable ) |
▶ ELECTRONIC CHARACTERISTICS
|
CONDITIONS |
MIN |
STANDARD |
MAX |
UNIT |
|
Power supply |
Standard |
11.5 |
12 |
24 |
36 |
V |
Working current |
No load |
|
40 |
|
mA |
|
Output overload |
Resistive |
|
400 |
1000 |
kΩ |
|
Working temperature |
|
-40 |
|
+85 |
℃ |
|
Store temperature |
|
-40 |
|
+85 |
℃ |
