Product Details
Place of Origin: China
Brand Name: RION
Certification: CE
Model Number: TL735-485
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 60
Packaging Details: carton box with sponge
Delivery Time: 5 days for samples
Payment Terms: L/C, T/T
Supply Ability: 5000/month
Azimuth Measurement Axi: |
Z-axis Azimuth Angle ±1 |
Product Name: |
Gyro For 5G Antenna |
Acquisition Bandwidth: |
>100Hz |
Azimuth Resolution: |
0.01deg |
Azimuth Accuracy: |
<0.5° |
Input Voltage: |
9~36V, Default +24VDC, 12mA |
Azimuth Measurement Axi: |
Z-axis Azimuth Angle ±1 |
Product Name: |
Gyro For 5G Antenna |
Acquisition Bandwidth: |
>100Hz |
Azimuth Resolution: |
0.01deg |
Azimuth Accuracy: |
<0.5° |
Input Voltage: |
9~36V, Default +24VDC, 12mA |
high performance gyro sensor for antenna, 5g antenna heading angle sensor, pitch roll safety tilt sensor
TL735G is a high-precision three-axis attitude meter developed by RION Technology based on the company's latest MEMS inertial measurement platform. It outputs the horizontal azimuth angle and angular rate of the object in real time by performing dynamic attitude algorithm on the angular rate of the gyroscope. The product integrates RION’s patented inertial navigation algorithm. Through the multi-model data fusion of the attitude angle, the short-term drift of the gyroscope can be solved to the greatest extent.
The azimuth angle of this product has a power-down storage function, and is suitable for high-voltage rotary switch angle indications in 5G antenna monitoring, outdoor billboards, and other industries.
▶ MAIN FEATURE
★ Super electromagnetic compatibility
★ Real-time angular rate output
★ Horizontal azimuth and attitude angle output
★ Long life, strong stability
★ Forward axis acceleration
★ All solid state
★ Compact and lightweight design
★ RS485 output optional
★ DC9~36V power supply
▶ APPLICATION
★ 5G antenna monitoring
★ Outdoor billboard
★ 3D virtual reality
★ Stable platform
★ Car security system
★ Drone
★ Vehicle-mounted satellite antenna equipment
★ Industrial control
★ Robot
| TL735G | Parameters |
| Azimuth measurement axis | Z-axis azimuth angle ±180° |
| Acquisition bandwidth | >100Hz |
| Azimuth resolution | 0.01° |
| Azimuth accuracy | <0.5° |
| Non-linear | 0.1% of FS |
| Pitch accuracy | 0.1° RMS |
| Roll accuracy | Dynamic 0.5°, static 0.1° RMS |
| Tilt resolution | 0.01° |
| Tilt range | Roll ± 180º, pitch ± 90º |
| Gyro angular rate | ±125 °/s (other angular rates can be customized) |
| Acceleration range | ±2g |
| Acceleration resolution | 0.1° |
| Acceleration accuracy | 0.5mg |
| Default data output type | Euler angle |
|
Default azimuth measurement range (Data output type is Euler angle) |
±180° |
| Start Time | 5s (stationary) vibration <10mg |
| Input voltage | 9~36V, default +24VDC, 12mA |
| Current | 40mA |
| Operating temperature | -40℃ ~ +85℃ |
| Storage temperature | -40 ℃~ +125℃ |
| Vibration | 5g~10g |
| Impact | 200g pk,2ms,½sine |
| life span | 10 years |
| Start Time | 5-6 seconds, stand still (acceleration <0.01g) |
| Maximum sampling rate | 100 times/sec |
| Serial communication rate | Default 9600 baud rate |
| Output signal | RS485 |
| MTBF | ≥50000 hours/time |
| Insulation resistance | ≥100 megohm |
| Impact resistance | 100g@11ms, 3 Axial Direction (Half Sinusoid) |
| Anti-vibration | 10grms,10～1000Hz |
| Waterproof level | IP67 |
| Cable | Standard 1-meter cable |
| Weight | 35g (not including cable) |
▶ Installation
▶ PRODUCT ELECTRICAL CONNECTION
| Color Function | BLACK | WHITE | GREEN | RED | Shielded wire |
| GND | RS485(D+) | RS485(D-) |
Vcc 9～36V Positive pole |
Grounding(PE) |
