Product Details
Place of Origin: Guangdong, China
Brand Name: RION
Certification: CE, ISO
Model Number: LCA328T
Payment & Shipping Terms
Minimum Order Quantity: 10 Pieces
Price: $49.00/Pieces
Packaging Details: 1 unit digital inclinometer in each inner wodeen box with thick sponge inside, 50pcs packed in strong & safe carton
Delivery Time: 7 days for samples order
Payment Terms: T/T, Paypal
Supply Ability: 5000/month
Inclination Sensor Measuring Axis: |
Single Axis (default X Axis ) |
Range: |
Within 360 ° Is Optional |
Wide Voltage Input: |
DC9-36V |
Output Model: |
4-20mA |
Protection: |
IP67 |
Working Temperature: |
40 ~ + 85 ℃ |
High Vibration Resistance: |
>2000g |
High Resolution: |
0.02 ° |
Size: |
L90mm *W40mm * H26mm (customizable) |
Best Accuracy: |
0.1 ° |
Inclination Sensor Measuring Axis: |
Single Axis (default X Axis ) |
Range: |
Within 360 ° Is Optional |
Wide Voltage Input: |
DC9-36V |
Output Model: |
4-20mA |
Protection: |
IP67 |
Working Temperature: |
40 ~ + 85 ℃ |
High Vibration Resistance: |
>2000g |
High Resolution: |
0.02 ° |
Size: |
L90mm *W40mm * H26mm (customizable) |
Best Accuracy: |
0.1 ° |
|
Measure range
|
|
±30
|
±60
|
±90
|
°
|
||||
|
Measure axis
|
|
X
|
X
|
X
|
Axis
|
||||
|
Resolution
|
|
0.02
|
0.03
|
0.05
|
°
|
||||
|
Zero output
|
0° output
|
12
|
12
|
12
|
mA
|
||||
|
Measure accuracy@25℃
|
@25℃
|
0.1
|
0.1
|
0.15
|
°
|
||||
|
Long term stability
|
|
<0.5
|
<0.5
|
<0.5
|
°
|
||||
|
Zero Temp. coefficient
|
-40～85℃
|
±0.02
|
±0.02
|
±0.02
|
°/℃
|
||||
|
Sensitivity temp. coefficient
|
-40～85℃
|
≤150
|
≤150
|
≤150
|
ppm/℃
|
||||
|
Power on time
|
|
0.5
|
0.5
|
0.5
|
S
|
||||
|
Response time
|
|
0.02
|
0.02
|
0.02
|
S
|
||||
|
Response frequency
|
|
1～20
|
1～20
|
1～20
|
Hz
|
||||
|
EMC
|
According to EN61000 and GBT17626
|
|
|
|
|
||||
|
MTBF
|
≥45000 hours/times
|
|
|
|
|
||||
|
Insulation Resistance
|
≥100MΩ
|
|
|
|
|
||||
|
Impact resistance
|
100g@11ms,3 Axial Direction (Half Sinusoid)
|
|
|
|
|
||||
|
Anti-vibration
|
10grms,10～1000Hz
|
|
|
|
|
||||
|
Protection Grade
|
IP67
|
|
|
|
|
||||
|
Cables
|
standard configuration: 1 meter wearproof,grease proofing,wide temperature,Shielded cables 4*0.3mm2
|
|
|
|
|
||||
|
Weight
|
90g(without cable )
|
|
|
|
|
||||
|
PARAMETERS
|
CONDITIONS
|
MIN
|
STANDARD
|
MAX
|
UNIT
|
||||
|
Power supply
|
Standard
|
9
|
12,24
|
36
|
V
|
||||
|
Working current
|
50 mA
|
|
42
|
|
mA
|
||||
|
|
12V
|
|
26
|
|
mA
|
||||
|
|
24
|
|
17
|
|
mA
|
||||
|
Output
internal resistance
|
resistiveness
|
400
|
|
1000
|
kΩ
|
||||
|
Current sampling resistor
|
Advice
|
|
250
|
|
R
|
||||
|
Working temperature
|
|
-40
|
|
+85
|
℃
|
||||
|
Store temperature
|
|
-40
|
|
+85
|
℃
|
||||
