ACA616T CANOPEN WATER-PROOF AIR-PLUG HIGH RESOLUTION SINGLE AXIS INCLINATION

Name: ACA616T CANOPEN WATER-PROOF AIR-PLUG HIGH RESOLUTION SINGLE AXIS INCLINATION
Brand: Shenzhen Rion Technology Co., Ltd.
SKU: ACA616T-10
Price: 570.00 USD
Availability: InStock

Product Details

Place of Origin: Guangdong, China

Brand Name: RION

Certification: CE, ISO

Model Number: ACA616T-10

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $570.00/Pieces

Packaging Details: Carton

Delivery Time: 7 days for samples

Payment Terms: T/T,Paypal

Supply Ability: 3000/pcs

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      MEMS electronic gyroscope sensor, 3D electronic gyroscope sensor, DC5V high precision gyroscope sensor


Measure Range:	±10°	Measure Axis:	X
Resolution:	0.001°	Measure Accuracy:	0.003°（RMS）
Zero Temp. Coefficient:	±0.0004°/℃	Response Frequency:	20S
Anti-vibration:	10grms,10~1000Hz	Interface Type:	CAN OPEN
EMC:	According To EN61000 And GBT17626	Weight:	235g(without Cable)

Measure Range:	±10°
Measure Axis:	X
Resolution:	0.001°
Measure Accuracy:	0.003°（RMS）
Zero Temp. Coefficient:	±0.0004°/℃
Response Frequency:	20S
Anti-vibration:	10grms,10~1000Hz
Interface Type:	CAN OPEN
EMC:	According To EN61000 And GBT17626
Weight:	235g(without Cable)

Description

ACA616T CANOPEN WATER-PROOF AIR-PLUG HIGH RESOLUTION SINGLE AXIS INCLINATION

ACA616T CANOPEN WATER-PROOF AIR-PLUG HIGH RESOLUTION SINGLE AXIS INCLINATION

ACA616T & ACA626T-CAN OPEN Inclinometer
Developed by RION Technology, the ACA616T (single-axis) and ACA626T (dual-axis) are full-temperature compensated, high-precision inclinometers based on an advanced measurement platform.

Key Features:

Wide Operating Temperature Range: -40°C to +85°C, ensuring stability in harsh environments.
High Accuracy: Built-in 24-bit A/D converter and 5-stage signal processing for precise tilt/pitch angle measurement.
CAN OPEN Output: Compatible with industrial control systems.
Easy Installation: Mount directly onto surfaces using screws for automatic attitude calculation.
Robust Design: Excellent shock and vibration resistance.
Superior Performance: Outperforms competing domestic models in precision and reliability.

Applications:
Ideal for construction, aerospace, automotive testing, and robotics where high-end performance is critical

Detailed Data

ACA616T&626T-C1	CONDITIONS	PARAMETERS			UNIT
Measure range		±10	±30	±60	°
Measure axis		X/XY	X/XY	X/XY	AXIS
Resolution		0.001	0.001	0.001	°
Measure accuracy	@25℃	0.003	0.01	0.02	°(RMS)
Zero Temp. coefficient	-40~+85℃	±0.0004	±0.0004	±0.0004	°/℃
Sensitivity temp-coeffi	-40~+85℃	≤50	≤50	≤50	ppm/℃
Power on time		0.5	0.5	0.5	S
Response frequency		20	20	20	S
Output rate	10Hz,20Hz can be setting
Interface type	CAN OPEN
EMC	According to EN61000 and GBT17626
MTBF	≥98000 hours/times
Insulation Resistance	≥100MΩ
Shockproof	100g@11ms,3 Axial Direction (Half Sinusoid)
Anti-vibration	10grms,10～1000Hz
Protection grade	IP67
Cables	Standard configuration: 2m length, wear-resistant, wide temperature, shielded cable 5P * 5.7mm aviation connector
Weight	235g(without cable)

ELECTRONIC CHARACTERISTICS

PARAMETERS	CONDITIONS	MIN	STANDARD	MAX	UNIT
Power supply	Standard	9	12,24	36	V
Power supply	customized		Other voltage		V
Working current	No load		50		mA
Working temperature		-40		+85	℃
Store temperature		-40		+85	℃

▶ PRODUCTION INSTALLATION NOTES

Please follow the correct way to install tilt sensor, incorrect installation can cause measurement errors, with particular attention to the "surface", "line" :1) The Sensor mounting surface and the measured surface must be fixed closely, smoothly, stability,if mounting surface uneven likely to cause the sensor to measure the angle error.

2) The sensor axis and the measured axis must be parallel ,the two axes do not produce the angle as much as possible.

ACA616T CANOPEN WATER-PROOF AIR-PLUG HIGH RESOLUTION SINGLE AXIS INCLINATION 2

▶ MEASURING DIRECTIONS

The installation must guarantee the product bottom is parallel to measured face,and reduce the influence of dynamic and acceleration to the sensor. This product can be installed horizontally or mounted vertically (mounted vertically selection must confirm before production ), for installation please refer to the following scheme.

ACA616T CANOPEN WATER-PROOF AIR-PLUG HIGH RESOLUTION SINGLE AXIS INCLINATION 3
