Product Details
Place of Origin: China
Brand Name: RION
Certification: CE, ISO
Model Number: SCA126W-10
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: 260 USD/pcs
Packaging Details: Carton
Delivery Time: 10 days
Payment Terms: T/T, PayPal
Supply Ability: 1000/month
Measure Range: |
10~90 Deg |
Measure Axis: |
X/Y/XY |
Resolution: |
0.01° |
Measure Accuracy: |
0.02° |
Long Term Stability: |
0.05° |
Weight: |
220g |
Zero Temperature Coefficient: |
±0.006°/℃ |
Power Supply: |
Li Battery |
Measure Range: |
10~90 Deg |
Measure Axis: |
X/Y/XY |
Resolution: |
0.01° |
Measure Accuracy: |
0.02° |
Long Term Stability: |
0.05° |
Weight: |
220g |
Zero Temperature Coefficient: |
±0.006°/℃ |
Power Supply: |
Li Battery |
Highly Anti-Vibration Wireless Inclinometer Meter With ±1-90° Measuring Range
Features:
●Dual-Axis Inclinometer
●Measuring Range :±1～±90° optional
●Accuracy: refer to the technical data
●Wide voltage input: 9～36V
●Wide temperature working: -40～+85℃
●Resolution: 0.01°
●IP67 protection class ●Highly anti-vibration performance >2000g
●200M wireless transmission
●Small size : 97×50×48.5mm
●Output mode RS232/RS485/RS422 (optional)
Application:
●engineering mechanical measurement of dip angle
●oil-well drilling equipment
●Radar detection of vehicle platform
●Underground drill posture navigation
●Gun Barrel angle measurement in early shooting
●Based on the angle direction measurement
●Satellite communications vehicle posture detection
●Shield pipe jacking application
●Ship’s navigation posture measurement
●Geological equipment inclined monitoring
▶ TECHNICAL DATA
| Measuring rang | ±10 | ±30 | ±60 | ±90 | ° | |
| Measuring axis | X,Y | X,Y | X,Y | X,Y | ||
| Resolution | 0.01 | 0.01 | 0.01 | 0.01 | ° | |
| Absolute accuracy | 0.02 | 0.05 | 0.08 | 0.1 | ° | |
|
Long term stability |
0.05 | 0.05 | 0.05 | 0.05 | ||
|
Zero temperature coefficient |
-40～85° | ±0.006 | ±0.006 | ±0.006 | ±0.006 | °/℃ |
| Sensitivity temperature coefficient | -40～85° | ≤100 | ≤100 | ≤100 | ≤100 | ppm/℃ |
| Power on time | 0.5 | 0.5 | 0.5 | 0.5 | S | |
| Response time | 0.05 | 0.05 | 0.05 | 0.05 | S | |
| Output rate | 5Hz,15Hz,35Hz,50Hz can be setting | |||||
| Output signal | RS232/RS485 | |||||
| EMC | According to EN61000 and GBT17626 | |||||
| MTBF | ≥50000hours/times | |||||
| Insulation Resistance | ≥100M | |||||
| Shockproof | 100g@11ms,3Times/Axis(half sinusoid)) | |||||
| Anti-vibration | 10grms,10～1000Hz | |||||
| Protection glass | IP67 | |||||
| Cables |
Standard 1M length,wearproof,grease proofing,wide temperature, Shielded cables 4*0.4mm2 |
|||||
| Weight | 220g(without cable) | |||||
