BDA450 Bluetooth Dynamic Attitude Sensor with 3D Motion Measurement for Robots and Mobile Machinery

BDA450 Bluetooth Dynamic Attitude Sensor.pdf

APPLICATION FIELD

• Leveling and flattening
• Robot applications
• Mobile machinery
• Agricultural machinery
• Boring and drilling applications
• Elevated platforms
• Mobile elevators and fire trucks
• Cranes and construction machinery
• Automatic Guided Vehicles (AGV)
• Automatic assembly machinery

MAIN FEATURES

• Low noise
• Bluetooth 5.1 wireless transmission
• Solar power supply
• Kalman filtering algorithm
• Real time 3D dynamic measurement
• Long lifespan, strong stability
• Maximum update rate of 100Hz
• High performance drift stability
• Integrated nine axis sensor and temperature sensor

SPECIFICATIONS

1) Accuracy: Refers to the root mean square difference between the measured value and the actual angle error obtained by measuring the angle multiple times (>16 times) at room temperature.

2) Zero point temp. Coefficient: refers to the rate of change in the displayed value of a sensor relative to normal temperature within its rated operating temperature range when it is in a zero state.

3) Sensitivity temp. Coefficient: refers to the percentage of full-scale indication of a sensor relative to full-scale indication at room temperature within its rated operating temperature range, and the rate of change with temperature.

MEASUREMENT DIRECTION

Please install the tilt sensor according to the correct method. Incorrect installation can cause measurement errors, especially paying attention to the first "surface" and second "line":

1. The installation surface of the sensor must be tightly, smoothly, and stably fixed to the measured surface. If the installation surface is uneven, it can easily cause measurement angle errors in the sensor.
2. The axis of the sensor must be parallel to the axis of the object being measured, and the two axes should not form an angle as much as possible.
