Product Details
Place of Origin: Guangdong, China
Brand Name: RION
Certification: CE
Model Number: MCA416T-485
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: $35/Pieces
Packaging Details: CARTON
Delivery Time: 7 days for samples
Payment Terms: T/T, Paypal
Supply Ability: 10000 per Month
Usage: |
Level Sensor |
Theory: |
Capacitance Sensor |
Output: |
Digital Sensor |
Product Name: |
Inclinometer |
Measuring Axis: |
X/Y |
Power Supply: |
DC 9~36V |
Measuring Range: |
Within 360 Deg |
Best Accuracy: |
<0.2° |
Angle Resolution: |
0.1° |
Working Temperature: |
-40°~ +85℃ |
Size: |
L61*W35*H21mm |
Response Time: |
0.05s |
Certificate: |
CE ISO |
Port: |
SHENZHEN |
Usage: |
Level Sensor |
Theory: |
Capacitance Sensor |
Output: |
Digital Sensor |
Product Name: |
Inclinometer |
Measuring Axis: |
X/Y |
Power Supply: |
DC 9~36V |
Measuring Range: |
Within 360 Deg |
Best Accuracy: |
<0.2° |
Angle Resolution: |
0.1° |
Working Temperature: |
-40°~ +85℃ |
Size: |
L61*W35*H21mm |
Response Time: |
0.05s |
Certificate: |
CE ISO |
Port: |
SHENZHEN |
General Description
MCA426M is a MODBUS output inclinometer designed especially for industrial position control. It adopts RS485 hardware differential bus transmit data. It built-in high accuracy 12 bit A/D differential conventor, using third order filter algorithm to measure the pitch and roll angle relate to horizontal level. It could redress the temperature drift according to the inside temperature change, ensuring the high repeatability when it is under high and low temperature. The output respond frequency could reach 20Hz, high frequency could be customized. It is industrial level product with reliable performance, good expandability, multiple output types are optional, and it could apply to kinds of harsh industrial working condition.
Feature
●single/dual axis
●measuring range ±45°
●accuracy:±0.5°
●DC 9~36V input
●working temp-40~+85℃
●resolution: 0.1°
●IP66
●anti-shock>2000g
●direct lead interface
●size:L61×W35×H21mm
●output type: MODBUS
|
Item
|
Conditions
|
≤±30°
|
≤±60°
|
≤±90°
|
≤±360°
|
Unit
|
|||||
|
Resolution
|
|
|
|
|
|
°
|
|||||
|
Accuracy
|
25℃
|
|
|
|
|
°
|
|||||
|
Response time
|
|
|
|
|
|
S
|
|||||
|
|
-5~55℃
|
±0.5
|
±0.5
|
±0.5
|
±0.5
|
°
|
|||||
|
|
-25~70℃
|
±0.7
|
±0.7
|
±0.7
|
±0.7
|
°
|
|||||
|
|
-40~85℃
|
±0.8
|
±0.8
|
±0.8
|
±0.8
|
°
|
|||||
|
Output load
|
>500 ohm
|
|
|
|
|
|
|||||
|
Working time
|
50000 hours/time(no fault)
|
|
|
|
|
|
|||||
|
Insulation resistance
|
>100 ohm
|
|
|
|
|
|
|||||
|
Anti-shock
|
10grms,10~1000Hz
|
|
|
|
|
|
|||||
|
Impact resistance
|
100g@11ms,times/axis(half sinusoid)
|
|
|
|
|
|
|||||
|
Weight
|
60g
|
|
|
|
|
|
|||||
|
Certificate
|
CE;FCC;CCC;
|
|
|
|
|
|
|||||
|
Production standard
|
GB/T 191 SJ 20873-2003 tilt sensor,level sensor general specification
|
|
|
|
|
|
|||||
|
Quality system
|
ISO9001:2008 standard(certificate No.:128101)
|
|
|
|
|
|
|||||
